CLW5251ZSLD5 Model technical parameters | |||
Name: | CLW5251ZSLD5 | Exterior size(mm): | 10980,9990×2480×3930 |
Chassis: | DFH1250BXV | Container size(mm): | ×× |
Total weight :(kg) | 25000 | Approach angle/ Departure angle(° ) | 23/11,23/10 |
Payload:(kg) | 14055 | Front suspension/rear suspension(mm): | 1430/2750,1430/2660 |
Kerb Mass:(kg) | 10750(Kg) | Max Speed(km/h): | 98 |
Chassis parameters | |||
Chassis: | DFH1250BXV | Axle weight: | 7000/7000/11000 |
Number of axles: | 3 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 1800+3800,1800+4100,1800+5000 | Fronttread(mm): | 1915/1915,1955/1955 |
Max people in cab: | 3 | Rear tread(mm): | 1860 |
Number of tires: | 8 | Number of spring axle: | 10/10/10+8,10/10/11+8 |
Tire Type: | 295/80R22.5 18PR,11.00R20 18PR,12R22.5 18PR | ||
introduction: | 罐体外形尺寸:8100×2480×2150(mm);罐体有效容积:29.5立方米;介质:膨化及颗粒饲料,粉料;密度:500kg/立方米;运输介质:膨化及颗粒饲料、粉料;外形长/轴距/后悬对应关系为(mm): 10980/1700+5100/2750,10980/1800+5000/2750,9990/1700+4200/2660, 9990/1800+4100/2660。防护材料:Q235A碳钢,后防护采用焊接连接。后防护截面高度尺寸:50×100(mm),下边缘离地高度445mm。本车仅选用的发动机型号 |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
ISD210 50 | 东风康明斯发动机有限公司 | 6700 | 155 |
other parameters |
Introduction: |
more Picture: |
※ Need more information or pictures?please contact us and we will provide best service!。 |
