CLW5110ZSLE5 Model technical parameters | |||
Name: | CLW5110ZSLE5 | Exterior size(mm): | 7100,6950×2200×3400 |
Chassis: | EQ1111GLJ | Container size(mm): | ×× |
Total weight :(kg) | 11495 | Approach angle/ Departure angle(° ) | 22/14 |
Payload:(kg) | 5595,5530 | Front suspension/rear suspension(mm): | 1250/2050 |
Kerb Mass:(kg) | 5770(Kg) | Max Speed(km/h): | 90 |
Chassis parameters | |||
Chassis: | EQ1111GLJ | Axle weight: | 4825/6670 |
Number of axles: | 2 | Fuel Type: | Diesel fuel |
Wheelbase(mm): | 3650,3800,3950,4200,4500 | Fronttread(mm): | 1760,1810,1910 |
Max people in cab: | 2,3 | Rear tread(mm): | 1670,1690,1800 |
Number of tires: | 6 | Number of spring axle: | 8/11+8,8/10+7,11/9+7,9/10+8 |
Tire Type: | 8.25-20 16PR,8.25R20 16PR | ||
introduction: | 1、整车长/轴距/后悬对应关系为:7100/3800/2050,6950/3650/2050。2、防护材料:Q235A碳钢,连接方式:左右侧面防护装置采用焊接连接,后部防护断面尺寸(mm):200×50,采用焊接连接,后部防护离地高度(mm):420。3、ABS型号为3631010-C2000,生产厂家为东科克诺尔商用车制动系统(十堰)有限公司。4、随底盘选装驾驶室。油耗对应关系(L/100km):23.8(CY4BK151),23.8(4DX23-140E5),23.8(CY4SK251),24.4(Y |
Engine parameters | |||
Type | Manufacturer | Displacement(ml) | Power(kw) |
CY4BK151 | 东风朝阳朝柴动力有限公司 | 3856 | 105 |
